SlimSAS SFF8654 to 2*Mini SAS SFF8087

SlimSAS SFF8654 to 2*Mini SAS SFF8087 Featured Image
  • SlimSAS SFF8654 to 2*Mini SAS SFF8087

Short Description:

  • ADAPTER END: SlimSAS SFF-8654 8i

  • BACKPLANE: x2 MiniSAS SFF-8087 Cable
  • Compatible Devices: Personal Computer
  • Special Feature: Data Transfer



We are manufacturer that could support you good quality with aggressive price. Believe that we are the best choice for you from many traders and resellers.

Accepted OEM/ ODM

● Product origin: China

● Delivery time: 7 -10 workdays

Welcome to send us any of your questions and inquiries, we are more than pleasure to send you more information


Parameter Details

Product Detail

Product Tags

Specification
Application field

1.Server

2.Data storage

3.Workstation



Features and advantages

1.Smaller size connectors and cables save equipment space

2.Provide 8-channel signal transmission according to industry standards

3.Data speed: each channel supports UPI 11.2GT/s, SAS4.0 24Gbps, OpenCAPI 25Gbps and PCIe 4.0 16Gbps

4.Comply with SAS4.0 and SlimSAS SFF-8654 specifications



Mechanical behavior

1.Combining force: 55.5N max

2.Releasing force: 49N max

3.Rated durability period: at least 250 cycles



Electrical performance

1.Voltage: 30VDC per contact SlimSAS 8i plug: maximum 80mohm initial, maximum 20mohm after pressure test.

2.Dielectric withstand voltage: minimum 300 VDC, lasting 100 ms

3.Insulation resistance: the minimum value between adjacent pins is 10MΩ



 Signal integrity

1.Impedance of mating connector: 100 +/- 10% ohm

2.Common mode impedance: in line with SAS4.0 specifications

3.Insertion loss: in line with SAS4.0 specification,

4.Maximum crosstalk: in line with SAS4.0 specifications



Environmental compliance

Comply with RoHS2.0 standard

China RoHS: Yes

Reach SVHC: Yes



FAQ

Question:   How is the warranty?

Answer:   Buydaccable.com ’s warranty for all the cables is 1 year.



Question:   Will you test all the products before shipment?

Answer:   Buydaccable.com will conduct spot checks for every batch of goods before shipment.



Question:  How do you ensure the quality of your products？

Answer:   Buydaccable.com is a professional manufacturer with over 10 years’ experience in High Performance Cables. We have strict quality control system and all the products have undergone severe compatibility test before launch in the market.
